HP15
Pola HP15 Two zone thermostat for heating or cooling
- Panel mount | 96x96mm
- Large digital display
- 2x NTC (-50/100°C)
- 2x 4(1)A SPDT relay
£208.26 £223.26Price range: £173.55£208.26 through £186.05£223.26
Excl. VAT & Incl. VAT
In Stock - Usually Delivered in 1-2 Days
Need Technical Support?
With 35 years of experience, we can help you select the right solution for your application and provide installation guidance.
General Description
Pola HP15 is a 2 zone digital thermostat for independent monitoring and control of temperature in 2 areas. ie. 2 different applications may be controlled from the same unit with different set points, sensors and sensor positions. This control is basicly two thermostats in one box.
2no. Pola SX thermistor sensors are supplied with ranges of -50.0/115.0 Deg.C or -58.0/239.0 Deg.F.
If you require a spare Pola SX sensor please click here.
Available as 96 x 96mm front panel mounting or IP54 surface/wall mount, it's large 20mm display makes for easy reading.
With 0.1 Degrees resolution, adjustable hysterisis from 0.2 Deg. and scale in C or F, the result is a versatile accurate thermostat.
Technical Specification
Power supply 230V +/- 10%
Mains frequency 50Hz +/- 20%
Power consumption 4W
2 x SPDT Output Relay:
Resistive contact rating 3 Amp 230V - AC1
Inductive contact rating 1 Amp 230V - AC3
Measuring range -50.0/115.0 Deg.C
Operating temperature -10/70 Deg.C
Measuring precision (Ambient 25 Deg.C) 0.1 Deg.C typical
Overall dimension 96 x 96 x 63 mm
Overall dimension (IP54 version) 98 x 125 x 75 mm
